UCP206 plummer block bearing
Insert bearings include screw locking style industrial series.These units combine a contact nitrile seal and an external slinger to provide superior protection from contamination and are adapted with a variety of housing styles.Insert bearings also include wide-inner-ring ball bearings that provide additional shaft support and locking options.These are designed for straight shafts and can be positioned without shoulders, locknuts or adapters.
Product picture&2D Drawing of UCP206 plummer block bearing
| Specifications |
| Features Shields |
Weights 1.73Kgs |
| Bemensions |
| Bore Sizes d 35.00mm |
| Total Height H2 94.00mm |
| Inside Ring Width B 42.90mm |
| H 47.60mm |
| L 167.00mm |
| J 127.00mm |
| A 48.00mm |
| Screw Diameter M14 |
| Basic Load Ratings |
| Cr Dynamic Load Rating 25.69kN |
| C0r Static Load Rating 14.02kN |
Spherical plain bearings can be used in many areas.
- The insert bearing is actually a kind of variation of deep groove ball bearing, which is characterized by the outer surface of its outer ring surface as a sphere, which can be inserted into the corresponding concave sphere of the bearing for the use of self-aligning.
- Agriculture machines,such as harvesters, straw returning machines, threshers,etc.
- Mining machines, metallurgy machinery, chemical industry, textile machines
- Ceramic machinery,printing and dyeing machines, conveying machinery.
SUN Bearing can provide professional consults to customer for your application fields and offer you specific application solutions with high efficiency and precise cost control.
Quality control of SUN Bearing for all bearing series
- Assembly
- Windage test
- Cleaning
- Rotary test
- Greasing and gland
- Noise inspection
- Apprearance inspection
- Rust prevention
- Product packing
Processing
Each bearing is 100% inspection by qualified inspectors and instruments in all above process.
A. Package instuctions of SUN Bearing for all bearing series
- Commercial packaging: 1pc/plastic bag + color box + carton + pallet
- Industrial packaging: a). plastic tube + carton + pallet; b). plastic bag + kraft paper + carton + pallet
- Customized packaging solutions according to customers' requirements
- High quality rubber cover: waterproof, wear-resisting, high temperature resistance,corrosion resistance
B. Shipping
- By courier like EMS, DHL, UPS, TNT, Fedex
- By air to air port
- By sea to sea port
- Select the best shipment mode after customers' confirmation through negotiations between us
- Generally it is 3-15days if the goods are in stock. Or it is 10-45days if the goods are not in stock, it is subject to customers' quantity.
- SUN Bearing can provider OEM or ODM service according to samples or drawings offered by customers.
- Lead time is usually 15-45days.
- Confirm the specifications of the customized bearing through researching application lines, environment&conditions,matched equipments specifications,etc.
- Assure the customized bearing complied with clients' requiements to give our customer the most stable use effect of the beairng.
